    Non Destructive Ultrasonic Flaw Detector 15MHz For Power Engineering

    Ask Lasest Price
    Brand Name : AE
    Model Number : SUB140
    Certification : CE、CQM
    Price : 2500 USD
    Payment Terms : T/T
    Supply Ability : 30 Piece/pieces per month
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    Non Destructive Ultrasonic Flaw Detector 15MHz For Power Engineering

    Ultrasonic flaw detector for precise non-destructive testing of welding defects, cracks and other defects

    Detailed introduction

    Non-destructive testing of internal defects such as pores. It is widely used in electric power engineering, boiler pressure vessel, steel structure, military industry, aviation, railway transportation, automatic mechanical equipment and other industries. It is an indispensable testing tool in the field of non-destructive testing.


    Key technical indicators
    ItemIndicatorItemIndicator
    Testing scope0~9999mmlinear inhibition0~80%(digital suppression)
    Working frequency0.2MHz~15MHzVertical linear error≤3%
    Sound velocity1000m/s~9999m/sHorizontal linear error≤0.1%
    Gain Coverage0dB~110dBDynamic Scope≥32dB
    Sampling rate100MHzBattery6*3.7V(lithium battery)
    Display delay-20μs~+3400μsElectricity8.4V
    Probe zero -offset0μs~99.99μsAmbient Temperature-20°C~50°C
    Level of electrical noise≤10%ambient humidity20%~90%RH
    Surplus sensitivity>63dBsize23cm*17cm*5.5cm
    Resolution Ratio>40dB(5P14)Weight1.56KGS(including leather case)

    Standard Configuration:


    No.DescriptionModelQty.
    1Detector(with wristlet)SUB1001
    2ChargerCD20L02QF1
    3Connecting cable1M2
    4Normal probeF20mm,2.5MHz1
    5Angle probe13′13k2,2.5MHz1
    6SUFD3 operating manualEnglish Manual1
    7PC softwareSupport Windows XP1
    8USB Disk2G1

    Company Information


    Shanghai Liangui Technology Co., Ltd. is committed to promoting the prosperity and development of the world through technology, focusing on Intelligent Equipment & Automation Solutions to to help enterprises to improve production process and minimize the cost.


    We are an intelligent equipment & automation solution integration service provider. Our company has a professional foreign trade sales team and an experienced technical support team, the principles of our team work is customer first and fast solution. Our business scope includes NDT Testing Equipment, Acoustic Emission Testing Instruments, Industrial Robot, Mechanical and Electrical Equipment etc.


    Our NDT testing division is specialized in the R & D, production, sales and technical application services of Acoustic Emission Testing Instruments, Ultrasonic Flaw Detector, Ultrasonic Thickness Gauge and other Testing Instruments. Our R&D team has the ability to develop Sensors, Electronic Measurement Software and Hardware, we can also customize Non-standard Automated and Robotic Inspection Equipment for customers. Our products mainly used in Industrial Field (Aerospace, Railway, Automotive, Oil & Gas, Manufacturing, Process Industry ) and Power Generation (Renewable, Nuclear, New Reactors, Advanced Reactors, Research Reactors, Gas Combined, Coal, Cogeneration).


    Our objective is to always help our clients meet their high safety standards, proposing efficient inspection solutions based on global services which reduce costs and increase process efficiency, make industrial facilities and power generation to operate safely, efficiently and excellently. Our major products AE system and instruments have been sold to China, USA, UK, Brazil, Indonesia and so on, which win the trust and support of customers from all over the world with an excellent reputation.

    FAQ

    Q1: How many MOQ?
    A: MOQ= 1piece


    Q2: How about the Lead time?
    A: For general parameter products,we can dispatch within 1-3 days after order confirmed.


    Q3: Do you offer the guarantee for your products?
    A:Yes, we offer 12 months warranty for our products.


    Q4:Can I get some discount?
    A: Different products have different discount,please contact us for details.


    Q5: Can I pay by T/T?
    A: Yes,you can,T/T and Paypal are supported.


    Q6: Do you have after sales technical guidance?
    A:Yes,any questions you can show us and our technical team will service for you at any time.


    Our services:


    Pre-Sales Service:

    * Inquiry and consulting support.

    After-Sales Service:

    * Training how to install the machine, training how to use and maintain the machine.
